Home / Product / 6700 Series Deep Groove Ball Bearing / 6707 ZZ/2RS Open 35x44x5mm High Speed Ball Bearings Thin Wall Bearing Deep Groove Ball Bearing
  • 6707 ZZ/2RS Open 35x44x5mm High Speed Ball Bearings Thin Wall Bearing Deep Groove Ball Bearing
  • 6707 ZZ/2RS Open 35x44x5mm High Speed Ball Bearings Thin Wall Bearing Deep Groove Ball Bearing

6707 ZZ/2RS Open 35x44x5mm High Speed Ball Bearings Thin Wall Bearing Deep Groove Ball Bearing

Specification

MODEL SIZE BASIC RATED LOAD WEIGHT
(reference)
kg
INNER DIAMETER(d)
mm
OUTER DIAMETER(D)
mm
WIDTH CHAMFER(r)
mm
DYNAMIC
Cr N
STATIC
Cor N
OPEN TYPE
mm
SHIELD TYPE
mm
6700 10 15 3 4 0.1 800 390 0.0019
6701 12 18 4 4 0.2 910 530 0.0031
6702 15 21 4 4 0.2 850 490 0.0036
6703 17 23 4 4 0.2 960 610 0.0040
6704 20 27 4 4 0.2 1030 720 0.0059
6705 25 32 4 4 0.2 1090 830 0.0070
6706 30 37 4 4 0.2 1170 980 0.0083
6707 35 44 5 5 0.3 1850 1630 0.0150
6708 40 50 6 6 0.3 2519 2234 0.0230

Precision Class
Standard Precision Class
GB/T307.1 P0 P6 P5 P4
IS0492 CLASS0 CLASS6 CLASS5 CLASS4
AFBMA STD.20 ABEC1 ABEC3 ABEC5  ABEC7

Bearing Material
Chrome Steel: Chemical Composition of Chrome Steel,According to customer needs, stainless steel bearing materials avaiable
Steel No Chemical Composition%
C Si Mn P S Cr
GCr15 0.95-1.05 0.15-0.35 0.20-0.40 ≤0.027 ≤0.02 1.30-1.65

The Interchange of Chrome Steel No.
Country China ISO U.S.A Germany Japan Sweden
Bearings
Steel No.
GCr15 683/VXⅡ  (AISI)52100 (DIN)100Cr6 (Jis)SUJ2 SKF3

Professional manufacture of 6707 ZZ/2RS Open 35x44x5mm High Speed Ball Bearings Thin Wall Bearing Deep Groove Ball Bearing.

15

Years Of Experience

We are an international custom 6707 ZZ/2RS Open 35x44x5mm High Speed Ball Bearings Thin Wall Bearing Deep Groove Ball Bearing suppliers and OEM/ODM 6707 ZZ/2RS Open 35x44x5mm High Speed Ball Bearings Thin Wall Bearing Deep Groove Ball Bearing company, specialized in the manufacturing deep groove ball bearing. Not only advanced automated production equipment, strict enterprise management, excellent talent team, and strong technology, rigorous process, but also we have a large number of precision grinding machine, mainly use high-quality bearing steel "GCr15" as raw material, and low-carbon alloy steel as attached. The first inspection, Operator self-inspection, inspect all the sizes; Inspect sampling, factory finished product testing and other processes, custom 6707 ZZ/2RS Open 35x44x5mm High Speed Ball Bearings Thin Wall Bearing Deep Groove Ball Bearing quality has been Strict controlled. Our quality goal is the pursuit of excellence, achieve customer satisfaction.
We have professional design, development and manufacture of 6707 ZZ/2RS Open 35x44x5mm High Speed Ball Bearings Thin Wall Bearing Deep Groove Ball Bearing and deep groove ball bearings. Our leading products are widely used in micro-electromechanical, household appliances, electric fans, washing machines, motorcycles, electric vehicles, medical equipment, sports equipment, textile and agricultural machinery, and process decorations, sliding doors and windows, children′s toys, trolleys, Package, skates, scooters, fitness equipment, various types of machinery sector!
